Airport Construction Stabilized Soil Mixing Station 125KW To 200KW

1 unit
Airport Construction Stabilized Soil Mixing Station 125KW To 200KW
Features Gallery Product Description Request A Quote
Capacity: 100-200t/h
Max. Aggregate Size: 60mm
Additive Weighing Range: 15-50kg
Aggregate Bin Volume: 4×7m³
Discharging Height: 3.8m
Product Name: Soil Cement Mixing Plant
Total Power: 90kw
Cement Weighing Range: 600-1500kg
High Light:

Airport Construction Stabilized Soil Mixing Station


Stabilized Soil Mixing Station 125KW


Airport Construction Stabilized Soil Mixing Plant

Basic Infomation
Payment & Shipping Terms
Packaging Details: Bare Packing
Delivery Time: 15 days
Payment Terms: deposit, full payment before shipment
Supply Ability: 1-100 units/month
Product Description

Product Description:

A soil cement mixing plant is a facility that is used to mix soil, cement, and water to produce a soil-cement mixture for use in construction projects. The soil cement mixture is a highly durable and strong material that is commonly used as a base or subbase for roads, parking areas, and other structures.
The process of mixing soil and cement involves blending soil, cement, and water in a precise ratio to create a homogenous mixture. The mixture is then compacted and cured to create a solid, stable base.
Soil cement mixing plants can be used for a wide range of construction projects, including road construction, airport runways, and parking areas. They are particularly useful in areas where the soil is weak or unstable, as the soil-cement mixture provides a stable and strong base that can support heavy loads.


Product configuration:
1, Batching supply system: dividing hopper, speed-controlled frequency-controlled metering belt machine, belt conveyor.
2, Cement material supply system: cement silo (cement hopper), speed-controlled variable frequency metering impeller feeder, spiral electronic weighing conveyor.
3, Automatic water supply system: pressure tank, submersible pump, pipeline, pressure reducing valve, water flow meter, water sprinkler.
4, Mixing system: motor reducer, double horizontal shaft continuous mixer.
5, Storage bin device system: double discharge storage bin, inclined belt machine, air compressor.
6, Electrical system: operation control cabinet, operation room.
7, Measuring control system: Adopt domestic famous manufacturer electronic parts, frequency conversion speed control, microcomputer control manual and automatic two forms. This machine is equipped with bulk cement silo, (including screw conveyor). For bagged cement hopper, it can be equipped with another device according to the user's needs.


Technical Parameters:

WDJ300.400.500.600.700.800 type stabilized soil mixing plant main performance parameters:

Parameter ModelWDJ300WDJ400WDJ500WDJ600WDJ700WDJ800
Measuring methodComputerizedComputerizedComputerizedComputerizedComputerizedComputerized
Adjustment methodVariable frequency speed controlVariable frequency speed controlVariable frequency speed controlVariable frequency speed controlVariable frequency speed controlVariable frequency speed control
Control modeautomaticautomaticautomaticautomaticautomaticautomatic
Weighing accuracy (aggregate)±2%±2%±2%±2%±2%±2%
Weighing accuracy (powder)±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%
Main motor power37KW45KW60KW75KW90KW110KW
Total Weight24t24t27t27t30t30t
Total power115KW125KW140KW155KW180KW200KW

Support and Services:

Technical Support & Services for Soil Cement Mixing Plant

We provide technical support and services for our Soil Cement Mixing Plant products. Our experienced engineers and technicians are available to provide you with world-class technical solutions for your project. Our services include:

  • Installation and commissioning of the Soil Cement Mixing Plant
  • Troubleshooting and technical assistance
  • Regular maintenance and preventive maintenance services
  • Inspection and repair
  • Training for operators and maintenance personnel

We are committed to providing our customers with the best technical support and services available. If you have any questions or require assistance with your Soil Cement Mixing Plant, please do not hesitate to contact us.



Soil Cement Mixing Plant FAQs
Q: What kind of materials can be used in a soil cement mixing plant?
A: A soil cement mixing plant typically uses dry cement, soil, and water to mix a soil-cement material for use in various construction projects such as roadways, foundations, and walls.
Q: What is the output capacity of a soil cement mixing plant?
A: Output capacity of a soil cement mixing plant depends on its size and configuration. Generally, a soil cement mixing plant can process up to 50 tonnes of material per hour.
Q: What are the advantages of a soil cement mixing plant?
A: Soil cement mixing plants offer several advantages over traditional methods of soil cement mixing. They are efficient, require less labor, provide a consistent product, and reduce environmental impact.
Q: How long does it take to set up a soil cement mixing plant?
A: Depending on the size and complexity of the soil cement mixing plant, setup can take anywhere from a few hours to a few days.
Q: What kind of maintenance is required for a soil cement mixing plant?
A: Regular maintenance is required to ensure that the soil cement mixing plant is operating safely and efficiently. This includes checking for wear and tear, lubricating parts, and cleaning filters and other components.
