Our Soil Cement Mixing Plant is the ideal equipment for road construction. It has a large aggregate bin volume of 4x7m³, and can be operated in full automatic or semi-automatic or manual mode. The powerful mixer is driven by two motors with 37kw power each, and the whole station has a total power of 90kw. The cement weighing range is 600-1500kg. This Soil Cement Mixing Station is an essential tool for road construction.
Mobile or stationary design: Stabilized soil mixing plants can be either mobile or stationary, depending on the needs of the construction site. Mobile plants can be transported to different sites, while stationary plants are designed to remain in one location.
High production capacity: Stabilized soil mixing plants are designed to produce large quantities of stabilized soil quickly and efficiently, making them well-suited for large infrastructure projects.
Specification parameters.
WDJ300.400.500.600.700.800 type stabilized soil mixing plant main performance parameters:
| Parameter Model | WDJ300 | WDJ400 | WDJ500 | WDJ600 | WDJ700 | WDJ800 |
| Productivity | 300t/h | 400t/h | 500t/h | 600t/h | 700t/h | 800t/h |
| Measuring method | Computerized | Computerized | Computerized | Computerized | Computerized | Computerized |
| Adjustment method | Variable frequency speed control | Variable frequency speed control | Variable frequency speed control | Variable frequency speed control | Variable frequency speed control | Variable frequency speed control |
| Control mode | automatic | automatic | automatic | automatic | automatic | automatic |
| Weighing accuracy (aggregate) | ±2% | ±2% | ±2% | ±2% | ±2% | ±2% |
| Weighing accuracy (powder) | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
| Main motor power | 37KW | 45KW | 60KW | 75KW | 90KW | 110KW |
| Total Weight | 24t | 24t | 27t | 27t | 30t | 30t |
| Total power | 115KW | 125KW | 140KW | 155KW | 180KW | 200KW |
Product configuration:
1, Batching supply system: dividing hopper, speed-controlled frequency-controlled metering belt machine, belt conveyor.
2, Cement material supply system: cement silo (cement hopper), speed-controlled variable frequency metering impeller feeder, spiral electronic weighing conveyor.
3, Automatic water supply system: pressure tank, submersible pump, pipeline, pressure reducing valve, water flow meter, water sprinkler.
4, Mixing system: motor reducer, double horizontal shaft continuous mixer.
5, Storage bin device system: double discharge storage bin, inclined belt machine, air compressor.
6, Electrical system: operation control cabinet, operation room.
7, Measuring control system: Adopt domestic famous manufacturer electronic parts, frequency conversion speed control, microcomputer control manual and automatic two forms. This machine is equipped with bulk cement silo, (including screw conveyor). For bagged cement hopper, it can be equipped with another device according to the user's needs.
The Soil Cement Mixing Plant is a kind of lime stabilized soil mixing plant which is widely used in construction projects. It is suitable for road construction, airport construction, dam construction, and other infrastructure projects. Its main features include high production efficiency, low energy consumption, strong adaptability, stable performance, and easy operation. This soil cement mixing plant is mainly composed of aggregate bin, cement silo, weighing system, mixing host, control system, and other components. The soil cement mixing plant is easy to operate and maintain, and is an ideal choice for the construction projects.
| Q | A |
|---|---|
| What is a Soil Cement Mixing Plant? | A Soil Cement Mixing Plant is a machine used to mix soil and cement to form a homogeneous mixture that can be used for construction and road building purposes. |
| What are the benefits of using a Soil Cement Mixing Plant? | Using a Soil Cement Mixing Plant offers a number of benefits, including: faster and more consistent mixing of soil and cement, improved workability, and improved strength and durability of the final product. |
| How do Soil Cement Mixing Plants work? | Soil Cement Mixing Plants use a combination of horizontal and vertical augers to blend the soil and cement together in a rotating drum. The mixture is then forced through a mixing chamber, which evenly distributes the cement throughout the soil. |
| What types of Soil Cement Mixing Plants are available? | Soil Cement Mixing Plants come in a variety of sizes and capacities. There are stationary, portable and mobile plants available, as well as plants designed for specific applications such as road building, foundation pouring and more. |
| What safety features are included in a Soil Cement Mixing Plant? | Soil Cement Mixing Plants are designed with a number of safety features, including emergency shut-off switches, automatic shut-off when the augers become blocked, and emergency stop buttons. |
