A stabilized soil mixing plant is a type of construction equipment used to produce stabilized soil, which is a mixture of soil, cement, and other additives. Stabilized soil is commonly used in road construction, airport runways, and other infrastructure projects to create a strong and stable subbase or base layer.
The process of producing stabilized soil involves mixing soil, cement, and other additives in a predetermined ratio. The mixture is then compacted and cured to create a stable and durable base layer. The additives used in stabilized soil can include lime, fly ash, and other materials that improve the strength and durability of the mixture.
Stabilized soil mixing plants typically consist of a mixing chamber, cement silos, water tanks, and a control system. The mixing chamber is where the soil, cement, and other additives are combined and mixed to create the stabilized soil. The cement silos are used to store the cement, while the water tanks are used to store and supply water for the mixing process. The control system is used to monitor and control the mixing process, ensuring that the correct ratio of soil, cement, and additives is used.
Stabilized soil mixing plants can be designed to be stationary or mobile, allowing them to be used on construction sites of varying sizes and locations. They are particularly useful in areas where the soil is weak or unstable, as the stabilized soil provides a stable and strong base that can support heavy loads.
Product configuration:
1, Batching supply system: dividing hopper, speed-controlled frequency-controlled metering belt machine, belt conveyor.
2, Cement material supply system: cement silo (cement hopper), speed-controlled variable frequency metering impeller feeder, spiral electronic weighing conveyor.
3, Automatic water supply system: pressure tank, submersible pump, pipeline, pressure reducing valve, water flow meter, water sprinkler.
4, Mixing system: motor reducer, double horizontal shaft continuous mixer.
5, Storage bin device system: double discharge storage bin, inclined belt machine, air compressor.
6, Electrical system: operation control cabinet, operation room.
7, Measuring control system: Adopt domestic famous manufacturer electronic parts, frequency conversion speed control, microcomputer control manual and automatic two forms. This machine is equipped with bulk cement silo, (including screw conveyor). For bagged cement hopper, it can be equipped with another device according to the user's needs.
WDJ300.400.500.600.700.800 type stabilized soil mixing plant main performance parameters:
| Parameter Model | WDJ300 | WDJ400 | WDJ500 | WDJ600 | WDJ700 | WDJ800 |
| Productivity | 300t/h | 400t/h | 500t/h | 600t/h | 700t/h | 800t/h |
| Measuring method | Computerized | Computerized | Computerized | Computerized | Computerized | Computerized |
| Adjustment method | Variable frequency speed control | Variable frequency speed control | Variable frequency speed control | Variable frequency speed control | Variable frequency speed control | Variable frequency speed control |
| Control mode | automatic | automatic | automatic | automatic | automatic | automatic |
| Weighing accuracy (aggregate) | ±2% | ±2% | ±2% | ±2% | ±2% | ±2% |
| Weighing accuracy (powder) | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
| Main motor power | 37KW | 45KW | 60KW | 75KW | 90KW | 110KW |
| Total Weight | 24t | 24t | 27t | 27t | 30t | 30t |
| Total power | 115KW | 125KW | 140KW | 155KW | 180KW | 200KW |
A Soil Cement Mixing Plant is a specialized type of mixing equipment that is used to mix soil, cement and other materials together to form a cement-stabilized mixture. This type of system is ideal for large scale projects such as road construction, bridge foundations, and other civil engineering projects. Stabilized soil mixing plants are also used to create a homogenous, cohesive mixture of soils, aggregate, and cement-based materials. This mixture can be used for various applications, such as roads, pathways, and other large-scale construction projects.
We offer comprehensive technical support and services for our Soil Cement Mixing Plant. Our team of experienced professionals is always ready to provide you with the necessary assistance to get the most out of your Soil Cement Mixing Plant.
Our technical support and services are available 24/7, so you can always count on us to help you get the most out of your Soil Cement Mixing Plant.
